Heavy Duty Truck & Bus Washing Machine 10HP – 15 LPM, 250 Bar

  • Sarveshwari’s High Pressure Washer System delivers powerful industrial-grade cleaning with 250 Bar pressure for demanding applications.
  • Premium Italian-made Udor/Hawk triplex plunger pump ensures superior reliability and long service life.
  • High 17 LPM flow rate provides faster cleaning for vehicles, machinery, factories, and construction equipment.
  • Three-phase direct-coupled drive offers efficient power transmission with reduced maintenance requirements.
  • Ideal for automotive workshops, commercial wash stations, manufacturing plants, and industrial cleaning operations.



Why Sarv Garage Equipment Leads the Industry in India?

Get a Quote

Complete the form to receive your quote within 48 hours. You can also contact us directly at +91 91680 12124 or email us at info@garageequipments.com or book a demo

Product Information

Description
  • The High Pressure Washer System is a heavy-duty industrial cleaning machine engineered for high-performance cleaning in automotive, commercial, and industrial environments. Powered by a robust 10HP motor, it delivers exceptional cleaning power to remove stubborn grease, oil, mud, rust, dust, and other contaminants with ease.
  • Equipped with a genuine Udor/Hawk high-pressure triplex plunger pump manufactured in Italy, the system ensures consistent pressure, smooth operation, and extended equipment life even under continuous working conditions.
  • Delivering an impressive 17 litres per minute water flow at 250 Bar operating pressure, the washer significantly improves cleaning productivity while reducing overall wash time.
  • The direct-coupled transmission enhances efficiency by minimizing energy loss and ensuring stable pump performance with low maintenance requirements.
  • Designed for use in commercial vehicle wash centers, heavy machinery maintenance, manufacturing plants, warehouses, construction sites, agricultural facilities, and industrial cleaning operations.
  • Compatible with water temperatures up to 50°C, making it suitable for a wide range of professional cleaning applications.
  • High volumetric efficiency exceeding 90% ensures maximum cleaning performance with optimal water utilization.
  • Built using premium industrial-grade components, this washer is a dependable solution for businesses requiring powerful, reliable, and long-lasting cleaning equipment.



Technical Data
Pump Udon/Hawk- Made in Italy
Type High Pressure Triplex Plunger Pump
Flow Rate 15LPM
Pressure 250KG/CM2
Required Suction Pressure Flooded Suction Max. up to 2 Bar
Connection Size (BSP) Inlet ½” / Outlet 3/8” (Both Female Type)
Permissible Oil Temperature Room Temp. + 50 °C
Transmission Direct Couple
Lubrication Type / Grade / Quantity Splash / SAE 20 – 40 W / 1.5 Liter
Fluid / Max. Temp.: Water / 50 °C
Volumetric Efficiency >90% (Even if pumps are similar, their efficiency may differ by +2%, but overall it will be >90%)
Working Duty Intermittent
Technical Specifications

Motor Power 10 HP
Power Supply Three Phase
Pump Brand Udor / Hawk (Made in Italy)
Pump Type High Pressure Triplex Plunger Pump
Flow Rate 17 LPM
Working Pressure 250 Bar (250 KG/CM²)
Required Suction Pressure Flooded Suction Max. up to 2 Bar
Connection Size (BSP) Inlet ½” / Outlet 3/8″ (Female)
Transmission Direct Couple
Lubrication Type Splash
Oil Grade SAE 20–40 W
Oil Capacity 1.5 Litres
Fluid Type Water
Maximum Water Temperature 50°C
Permissible Oil Temperature Room Temperature +50°C
Volumetric Efficiency Greater than 90%
Working Duty Intermittent

Applications

Commercial car wash centers
Truck and bus washing facilities
Industrial machinery cleaning
Factory and warehouse maintenance
Construction equipment cleaning
Agricultural machinery washing
Fleet maintenance workshops
Building and concrete surface cleaning

Key Features

Powerful 10HP industrial motor
High 250 Bar cleaning pressure
Fast 17 LPM water flow
Premium Italian Udor/Hawk triplex plunger pump
Three-phase heavy-duty operation
Direct-coupled transmission system
Excellent cleaning efficiency above 90%
Low maintenance industrial design
Durable and corrosion-resistant construction
Suitable for continuous professional cleaning applications

Reliable Technical Support Across India

When you invest, you’re not just buying a machine—you’re getting complete support to keep your workshop running smoothly across India.

🛠️Hassle-free Installation: Our experts visit your location for proper setup and commissioning, so your machine is ready to use from day one.
🎓Easy-to-understand Training: We train your operators and workshop staff in simple terms, ensuring safe and efficient usage.
🌍Pan India Sales & Service Network: No matter where your garage is, our support team is always within reach.
⚙️Genuine Spare Parts: Quick access to original spare parts to avoid downtime and maintain performance.
📅Annual Maintenance Plans (AMC): Regular servicing options to keep your machine in top condition year-round.
📞Quick Troubleshooting Support: Get help instantly through calls or video support whenever you face an issue.
💻Remote Diagnostics: Our team can identify and guide you through fixes without waiting for a visit.
🧰Preventive Maintenance Guidance: Simple tips to help you avoid problems before they occur.
📏Scheduled Calibration & Servicing: Ensuring your alignment readings stay accurate over time.
🛡️Warranty Support: Coverage based on your machine model for added peace of mind.

In short, we make sure your machine works accurately, efficiently, and without interruptions—so you can focus on growing your business.
