220303 – Tube Tyre Truck Bus Tyre Removal Tool
- SARV’s Most Famous Manual Tyre Removal Tool Kit for Multipiece 20″ Truck Tube type Tires , simplifies the traditional way of openining and locking the rings.
- The Kit is specialised to Remove and replace 2 Piece and 3 peice rims on Truck 20″ Tube type Tyres.
- 220914 is a specialised tyre lever tool to remove Single Lock Ring on 2 peice Rims.
- It is very sturdy and made from forged high-grade carbon steel and heat-treated for long-lasting strength and durability.
- The Jaws of the tool are designed to securely fit on the lug nut hole and flange.
- The Lever takes the leverage against the lug nut to remove the flange/locking ring from the rim on 2 peice rims.
- Tyre levers 220008 and 220003 are ursed in removing the 3 peice rims. 220003 is inserted between the space between top most lock ring and 220008 is inserted between the two lock rings.
- applying enough pressure with both the levers, the lock rings starts to come out.
- Once the top lock rings comes out, it is easy to remove the second ring.
- Screw Driver is used for removing and installing the tyre valve core.
- Tyre Mounting levers or Ring Fitting Tools are made from high quality steel and heat treated for even greater strength.
- These are used in pairs and are designed to fit both 2 peice and 3 peice rims, keeping the concept same.
- One side of the lever has the leverage bar to take the leverage against the rim, for fitting the lock ring back.
- One Leverage bar side in inserted in the lug nut hole to press the lock ring back from one end.
- To avoid slippage, it is then kept in the same position, and other lever is positioned from other end to start pressing the lock ring. the same process is repeated for 2 or 3 peice rims.
- The kit contents have code numbers infront of them, which can be ordered again .
- Kit contains following items :
- Valve Core Screw Driver 330002 – 1 No.
- Ring Removal Tool 220914 – 1 No.
- Ring Fitting Tool 221014 – 2 Nos.
- Tyre Lever 220008 1 No.
- Tyre Lever Crank End 220003 – 1 No.
